16ch PoE 1.5U K Series AcuSense 4K NVR
📩 اطلب عرض سعر خاص بك
اضغط هنا للتواصل معنا والحصول على أفضل سعر
أجهزة تسجيل هيكفيجن ان في آر NVR
109 مشاهدة
رقم المنتج: DS-7716NXI-K4/16P
الشركة المصنعة: Hikvision
الوصف:
16ch PoE 1.5U K Series AcuSense 4K NVR
Automatic speed control fans are designed for running quietly and energy saving
Adopt Hikvision AcuSense technology to minimize manual effort and security costs
Efficient playback with AcuSearch technology
Accurate perimeter protection effectively reduces false alarms
Automatic cameras connection and configuration
Up to 16-ch IP camera inputs, plug & play with 16 Power-over-Ethernet (PoE) interfaces
H.265+/H.265/H.264+/H.264 video formats
Up to 3-ch@12 MP or 5-ch@8 MP or 10-ch@4 MP or 16-ch@2 MP decoding capacity
Up to 160 Mbps incoming bandwidth
Automatic speed control fans are designed for running quietly and energy saving
Adopt Hikvision AcuSense technology to minimize manual effort and security costs
Efficient playback with AcuSearch technology
Accurate perimeter protection effectively reduces false alarms
Automatic cameras connection and configuration
Up to 16-ch IP camera inputs, plug & play with 16 Power-over-Ethernet (PoE) interfaces
H.265+/H.265/H.264+/H.264 video formats
Up to 3-ch@12 MP or 5-ch@8 MP or 10-ch@4 MP or 16-ch@2 MP decoding capacity
Up to 160 Mbps incoming bandwidth
روابط مفيدة:
المواصفات:
Intelligent Analytics
AI by NVR
Facial recognition, perimeter protection, motion detection 2.0, AcuSearch
AI by Camera
Facial recognition, perimeter protection, motion detection2.0, ANPR
AcuSearch
By Camera
All channels
*: The camera should enable AcuSearch function
Perimeter Protection
By NVR
Video analysis (HD network camera, H.264/H.265) for human and vehicle recognition to reduce false alarm.
Up to 4 MP: 2-ch;
8 MP to 5 MP: 1-ch
By Camera
All channels
Target Recognition
Facial Detection and Analytics
Face picture comparison, human face capture, face picture search
Facial Detection and Analytics Performance
Up to 4 MP: 2-ch;
8 MP to 5 MP: 1-ch
Face Picture Comparison
8-ch
Face Picture Library
Up to 16 face picture libraries, with up to 50,000 face pictures in total (each picture ≤ 1 MB, total capacity ≤ 1 GB)
Motion Detection 2.0
By NVR
All channels, up to 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis for human and vehicle recognition to reduce false alarm
By Camera
All channels
Video and Audio
IP Video Input
16-ch
IP Speaker Input
4-ch
Incoming Bandwidth
160 Mbps
Outgoing Bandwidth
160 Mbps
HDMI Output
1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output
1-ch, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Video Output Mode
HDMI/VGA independent output
Audio Output
1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input )
Decoding
Decoding Format
H.265, H.265+, H.264, H264+
Recording Resolution
16 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
*: 16 MP is only available for channel 1.
Synchronous Playback
16-ch
Decoding Capability
AI on: 2-channel 12 MP@30 fps, 4-channel 8 MP@30 fps, 5-channel 6 MP@30 fps, 8-channel 4 MP@30 fps, 10-channel 3 MP@30fps, 16-channel 2 MP@30fps
AI off: 3-channel 12 MP@30 fps, 5-channel 8 MP@30 fps, 6-channel 6 MP@30 fps, 10-channel 4 MP@30 fps, 13-channel 3 MP@30fps, 16-channel 2 MP@30fps
Stream Type
Video, Video and Audio
Audio Compression
G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2
Network
Remote Connection
128
API
ONVIF (profile S/G); SDK; ISAPI
Compatible Browser
IE 11, Chrome 91, Firefox 88, Safari 12, Edge 91,or above version
Network Protocol
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Network Interface
1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces
PoE
Interface
16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power
≤ 200W
Standard
IEEE 802.3af/at
Auxiliary Interface
SATA
4 SATA interfaces
Capacity
Up to 16 TB capacity for each HDD
Serial Interface
2 RS-485 (half-duplex), 1 RS-232
Alarm In/Out
16/9;16/4
eSATA
1 eSATA interface;NA
USB Interface
Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
General
GUI Language
English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Hebrew, Ukrainian, Indonesian
Fan
Supports
Power Supply
100 to 240 VAC, 50 to 60Hz
Consumption
≤ 50 W (without HDD)
Working Temperature
-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity
10 to 90 %
Dimension (W × D × H)
440 × 391 × 72 mm (17.32 × 15.39 × 2.82 inch)
≤ 5kg (without HDD, 10 lb.)
Certification
CE
EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
Obtained Certification
CE,CB,REACH,WEEE,UKCA,RCM,IC
